| Place of Origin: | China |
|---|---|
| Certification: | ISO 9001 |
| Minimum Order Quantity: | 1 SET |
| Packaging Details: | Plyfilm or plywood suitable for sea shipping |
| Delivery Time: | 25-30 DAYS |
| Supply Ability: | 30 SETS PER MONTH |
| Weight: | 800 KG | Warranty: | 1 Year |
|---|---|---|---|
| Max. Welding Thickness: | 500um | Usage: | Lithium Battery |
| Welding Angle: | 90 Degrees | Voltage: | 220VAC |
| Certification: | CE | Battery Type: | 18650 Tesla |
| Power: | 3000W/5000W | Advantage: | High Efficient |
| Highlight: | Aluminum Ultrasonic Wire Bonding Machine,18650 Battery Ultrasonic Wire Bonding Machine,18650 Battery automatic wire bonder |
||
| Power supply | 220VAC±10%, 50Hz, reliable grounding, the maximum consumption rate is about 1200W |
| Ultrasonic frequency | 60KHz |
| Ultrasonic power | 0~30W, automatic switching between first and second welding |
| X axis adopts linear motor-repeat positioning accuracy can reach ±0.02mm | |
| Weldable aluminum wire diameter | 125~ 500um (5~20mil) |
| Working area | XY axis maximum: 400×400 (can be customized according to customer requirements) |
| Ultrasound time | 10~500ms, multi-channel |
| Welding pressure | 50~1200g, multi-channel |
| Welding angle | ±90 degrees |
| Vision system | PR microscope magnification is 0.5 times |
| Dimensions | about 1500mm*2200mm*1650mm (L*W*H) |
